1097808 | SICK SENSORS | BTF08-A1MM0341 Wire Draw Encoder ABS

₹ 202,465.80

Get Best Price on WhatsApp

Product Description

Connection type Cable, 8-wire, universal, 5 m
Supply voltage 4.5 V DC ... 32 V DC
Weight 1.62 kg
Measuring wire material Highly flexible stranded steel 1,4401 stainless steel V4A
Measuring wire diameter 1.35 mm
Weight (measuring wire) 7.1 g/m
Housing material, wire draw mechanism Aluminum (anodized), aluminum die cast (nickel-plated)
Spring return force 6 N ... 14 N 1)
Length of wire pulled out per revolution 200 mm
Life of wire draw mechanism Typ. 1,000,000 cycles 2) 3)
Actual wire draw length 3.2 m
Wire acceleration 40 m/s²
Operating speed 8 m/s



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1097808

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet
  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Not applicable for this product

Connection type - Cable, 8-wire, universal, 5 m

Supply voltage - 4.5 V DC ... 32 V DC

Power consumption - ≤ 1.5 W (without load)

Weight - 1.62 kg

Measuring wire material - Highly flexible stranded steel, 1.4401 stainless steel (V4A)

Measuring wire diameter - 1.35 mm

Weight (measuring wire) - 7.1 g/m

Housing material, wire draw mechanism - Aluminum (anodized), aluminum die-cast (nickel-plated)

Spring return force - 6 N ... 14 N

MTTFD (Mean Time to Dangerous Failure) - 230 years (EN ISO 13849-1)

EU Declaration of Conformity - ✔

UK Declaration of Conformity - ✔

ACMA Declaration of Conformity - ✔

Moroccan Declaration of Conformity - ✔

China RoHS - ✔

ECLASS 5.1.4 - 27270502

ECLASS 6.0 - 27270590

ECLASS 7.0 - 27270590

ECLASS 8.0 - 27270590

ECLASS 9.0 - 27270590
