XCE145C | TELEMECANIQUE SENSORS | Variable Length Thermoplastic Roller Lever

₹ 1,856.25

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

XCE145C

Original Equipment Manufacturer

TELEMECANIQUE SENSORS

Descripción
Specification Details
Range of Product OsiSense XC
Series Name Basic
Product Type Limit Switch
Application Medium duty
Body Type Fixed
Head Type Rotary head
Material Plastic and metal
Mounting / Fixing Mode By the body
Movement of Operating Head Rotary
Operator Type Spring return roller lever – Thermoplastic variable length
Switch Actuation By 30° cam
Type of Approach Lateral, 2 directions
Electrical Connection Screw-clamp terminals, capacity 1 × 1.5 mm²
Cable Entry Flexible rubber cable gland, outer diameter 6-9 mm
Contacts Insulation Form Za
Rated Operational Current (AC) Ie = 3 A at Ue = 240 V (A300, AC) :contentReference[oaicite:2]{index=2}
Rated Operational Current (DC) Ie = 0.3 A at Ue = 220 V (R300, DC) :contentReference[oaicite:3]{index=3}
Operating Rate Up to 120 cycles/min :contentReference[oaicite:4]{index=4}
Mechanical Durability 10,000,000 cycles :contentReference[oaicite:5]{index=5}
IP Protection IP65 :contentReference[oaicite:6]{index=6}
Ambient Operating Temperature -25 °C … +70 °C :contentReference[oaicite:7]{index=7}
Dimensions (W × H × D) Approx. 28 mm × 125 mm × 48 mm :contentReference[oaicite:8]{index=8}
Net Weight Approx. 0.175 kg (175 g) :contentReference[oaicite:9]{index=9}
