085527 | PEPPERL+FUCHS | Inductive Sensor

₹ 88,045.19

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

085527

Original Equipment Manufacturer

PEPPERL+FUCHS

Descripción

Parameter Details
Product Series / Family Name NBB
Ambient Air Temperature (Operation) -25 … +70 °C
Main Function Sensor (Proximity; Inductive)
Functions Inductive proximity sensor
Coating Material Nickel plating
Material Brass (housing), PBT (sensing face), PVC (cable)
Degree of Protection IP67
Sensing Distance 8 mm
Visual Position Indicator Yellow LED (switching state)
Digital Outputs 1 × digital output (PNP; complementary)
Connection Type Pre-wired
Compliant Standards UL, CSA, CCC
Supply Voltage DC 10–30 V
Cable Length 2 m
Diameter M18 / 18 mm
Protection Functions Reverse polarity, Short-circuit (pulsed)
Mounting Mode Flush mounting
Shape Cylindrical threaded
Type Inductive (proximity detection)
Number of Circuits 4-wire
Sampling Rate 500 Hz
Control Circuit Rated Current 200 mA / 0.2 A
