SPARECRUX is NOT an authorized distributor for SCHMERSAL

103008067 | SCHMERSAL | Safety-Monitoring Modules

₹ 32,022.42

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

103008067

Original Equipment Manufacturer

SCHMERSAL

Descripción

Specification Details
Product Type Description SRB-E-201ST
Part Number 103008067
Coil Voltage 24 V DC
Contact Configuration DPST-NC, SPST-NO
Safety Outputs 2 × 5.5 A
Signalling Output 1
Functions STOP 0, 1- or 2-channel control, start/auto-start, two-hand panel monitoring
Housing Material Glass-fibre reinforced thermoplastic, ventilated
Mounting DIN rail (EN 60715)
General Weight ≈ 130 g
Indicators 5 LEDs, diagnostics with error codes
Fail-safe Classification PL e, SIL 3, Category 4
Probability of Failure (PFH / PFD) PFH 2.66 × 10⁻⁹/h, PFD 2.42 × 10⁻⁵
Mission Time 20 years
Diagnostics & Protection Electronic fuse, wire break, cross-circuit, earth leakage detection, auto reset
IP Ratings IP20 (standard), IP40/IP54 variants
Standards EN ISO 13849-1, EN IEC 62061, IEC 61508, IEC 60947-5-1/3/5, IEC 60204-1
SCHMERSAL

103008067 | SCHMERSAL | Safety-Monitoring Modules

₹ 32,022.42
Specification Details
Product Type Description SRB-E-201ST
Part Number 103008067
Coil Voltage 24 V DC
Contact Configuration DPST-NC, SPST-NO
Safety Outputs 2 × 5.5 A
Signalling Output 1
Functions STOP 0, 1- or 2-channel control, start/auto-start, two-hand panel monitoring
Housing Material Glass-fibre reinforced thermoplastic, ventilated
Mounting DIN rail (EN 60715)
General Weight ≈ 130 g
Indicators 5 LEDs, diagnostics with error codes
Fail-safe Classification PL e, SIL 3, Category 4
Probability of Failure (PFH / PFD) PFH 2.66 × 10⁻⁹/h, PFD 2.42 × 10⁻⁵
Mission Time 20 years
Diagnostics & Protection Electronic fuse, wire break, cross-circuit, earth leakage detection, auto reset
IP Ratings IP20 (standard), IP40/IP54 variants
Standards EN ISO 13849-1, EN IEC 62061, IEC 61508, IEC 60947-5-1/3/5, IEC 60204-1
