1037138 | SICK SENSORS | SKM36-HFA0-S05 Motor feedback system

₹ 60,532.80

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1037138

Original Equipment Manufacturer

SICK SENSORS

Descripción

Shaft version Tapered shaft
Flange type / stator coupling Spring mounting plate, stator coupling
Dimensions See dimensional drawing
Weight ≤ 0.07 kg
Moment of inertia of the rotor 4.5 gcm²
Operating speed 9,000 min⁻¹, 9,000 U/min
Angular acceleration ≤ 500,000 rad/s²
Operating torque 0.2 Ncm
Start up torque + 0.3 Ncm
Permissible movement static ± 0.1 mm, - 0.4 mm, + 0.2 mm radial, axial, axial
Permissible movement dynamic

± 0.05 mm radial

± 0.1 mm axial

Life of ball bearings 3.6 x 109 revolutions



SICK SENSORS 1037138 SKM36-HFA0-S05 Motor feedback system
SICK SENSORS

1037138 | SICK SENSORS | SKM36-HFA0-S05 Motor feedback system

₹ 60,532.80
Shaft version Tapered shaft
Flange type / stator coupling Spring mounting plate, stator coupling
Dimensions See dimensional drawing
Weight ≤ 0.07 kg
Moment of inertia of the rotor 4.5 gcm²
Operating speed 9,000 min⁻¹, 9,000 U/min
Angular acceleration ≤ 500,000 rad/s²
Operating torque 0.2 Ncm
Start up torque + 0.3 Ncm
Permissible movement static ± 0.1 mm, - 0.4 mm, + 0.2 mm radial, axial, axial
Permissible movement dynamic

± 0.05 mm radial

± 0.1 mm axial

Life of ball bearings 3.6 x 109 revolutions
