SPARECRUX is NOT an authorized distributor for SICK SENSORS

1038050 | SICK SENSORS | AFS60E-BEAK001024 Absolute Encoder

₹ 39,401.60

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1038050

Original Equipment Manufacturer

SICK SENSORS

Descripción
Connection type Cable, 8-wire, universal, 1.5 m 1)
Supply voltage 4.5 ... 32 V
Power consumption ≤ 0.7 W (without load)
Mechanical design Blind hollow shaft
Shaft diameter 12 mm
Characteristics of the shaft Front clamp
Weight 0.2 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum die cast
Start up torque < 0.8 Ncm (+20 °C)
Operating torque < 0.6 Ncm (+20 °C)
Permissible movement static

± 0.5 mm (axial)

± 0.3 mm (radial)
Permissible movement dynamic

± 0.2 mm (axial)

± 0.1 mm (radial)
Operating speed ≤ 6,000 min⁻¹ 2)



SICK SENSORS 1038050 AFS60E-BEAK001024 Absolute Encoder
SICK SENSORS

1038050 | SICK SENSORS | AFS60E-BEAK001024 Absolute Encoder

₹ 39,401.60
Connection type Cable, 8-wire, universal, 1.5 m 1)
Supply voltage 4.5 ... 32 V
Power consumption ≤ 0.7 W (without load)
Mechanical design Blind hollow shaft
Shaft diameter 12 mm
Characteristics of the shaft Front clamp
Weight 0.2 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum die cast
Start up torque < 0.8 Ncm (+20 °C)
Operating torque < 0.6 Ncm (+20 °C)
Permissible movement static

± 0.5 mm (axial)

± 0.3 mm (radial)
Permissible movement dynamic

± 0.2 mm (axial)

± 0.1 mm (radial)
Operating speed ≤ 6,000 min⁻¹ 2)
