SPARECRUX is NOT an authorized distributor for SICK SENSORS

1057078 | SICK SENSORS | LFP0700-A4NMB Level Sensor

₹ 43,893.60

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1057078

Original Equipment Manufacturer

SICK SENSORS

Descripción
Medium Fluids
Measurement Switch, Continuous
Design Standard
Probe type Rod probe
Probe length 700 mm
Process pressure –1 bar ... 10 bar
Process temperature –20 °C ... +100 °C
Communication interface IO-Link
Supply voltage 12 V DC ... 30 V DC 1)
Power consumption ≤ 100 mA at 24 V DC without output load
Initialization time ≤ 5 s
Protection class III
Connection type Round connector M12 x 1, 5-pin
Output signal 1 x PNP + 1 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V
Output load 4 mA ... 20 mA < 350 Ohm at Uv > 12 V, 0 V ... 10 V > 750 Ohm at Uv 14 ≥ V
Hysteresis ≥ 2 mm 2)
Output current < 100 mA
Inductive load < 1 H



SICK SENSORS 1057078 LFP0700-A4NMB Level Sensor
SICK SENSORS

1057078 | SICK SENSORS | LFP0700-A4NMB Level Sensor

₹ 43,893.60
Medium Fluids
Measurement Switch, Continuous
Design Standard
Probe type Rod probe
Probe length 700 mm
Process pressure –1 bar ... 10 bar
Process temperature –20 °C ... +100 °C
Communication interface IO-Link
Supply voltage 12 V DC ... 30 V DC 1)
Power consumption ≤ 100 mA at 24 V DC without output load
Initialization time ≤ 5 s
Protection class III
Connection type Round connector M12 x 1, 5-pin
Output signal 1 x PNP + 1 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V
Output load 4 mA ... 20 mA < 350 Ohm at Uv > 12 V, 0 V ... 10 V > 750 Ohm at Uv 14 ≥ V
Hysteresis ≥ 2 mm 2)
Output current < 100 mA
Inductive load < 1 H
