SPARECRUX is NOT an authorized distributor for SICK SENSORS

1059028 | SICK SENSORS | AFM60B-S4AM008192 Absolute Encoder

₹ 49,347.20

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1059028

Original Equipment Manufacturer

SICK SENSORS

Descripción
Connection type Cable, 8-wire, universal, 5 m 1)
Supply voltage 4.5 ... 32 V
Power consumption ≤ 0.7 W (without load)
Mechanical design Solid shaft, face mount flange
Shaft diameter 10 mm
Shaft length 19 mm
Characteristics of the shaft With flat
Weight 0.3 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum die cast
Start up torque < 0.5 Ncm (+20 °C)
Operating torque < 0.3 Ncm (+20 °C)
Permissible shaft loading

80 N (radial)

40 N (axial)
Operating speed ≤ 9,000 min⁻¹ 2)



SICK SENSORS 1059028 AFM60B-S4AM008192 Absolute Encoder
SICK SENSORS

1059028 | SICK SENSORS | AFM60B-S4AM008192 Absolute Encoder

₹ 49,347.20
Connection type Cable, 8-wire, universal, 5 m 1)
Supply voltage 4.5 ... 32 V
Power consumption ≤ 0.7 W (without load)
Mechanical design Solid shaft, face mount flange
Shaft diameter 10 mm
Shaft length 19 mm
Characteristics of the shaft With flat
Weight 0.3 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum die cast
Start up torque < 0.5 Ncm (+20 °C)
Operating torque < 0.3 Ncm (+20 °C)
Permissible shaft loading

80 N (radial)

40 N (axial)
Operating speed ≤ 9,000 min⁻¹ 2)
