SPARECRUX is NOT an authorized distributor for SICK SENSORS

1062978 | SICK SENSORS | PAC50-CCB Pressure Sensor

₹ 13,154.40

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1062978

Original Equipment Manufacturer

SICK SENSORS

Descripción

Medium Dry compressed air
Pressure type Gauge pressure
Pressure unit bar
Measuring range 0 bar ... 6 bar
Overpressure safety 15 bar
Process temperature 0 °C ... +60 °C
Maximum ohmic load RA Optional, 4 mA ... 20 mA / 0 V… 10 V. Automatic detection depending on connected load or programmable. Output signals can be inverted: 20 mA ... 4 mA / 10 V ... 0 V, Load resistance for current output < 600 Ohm, Load resistance with current output > 3 kOhm
Communication interface -
Process connection PIF 4 mm + G ¼ 1)
Housing material Housing: polycarbonate, Buttons: TPE, DIN rail mounting: POM, seals: NBR
Connection type M12 round connector x 1, 4-pin
Supply voltage 17 V DC ... 30 V DC
Power consumption Max. 40 mA at L+ = 24 VDC



SICK SENSORS 1062978 PAC50-CCB Pressure Sensor
