1103455 | SICK SENSORS | LFP0700-A5CMC Level Sensor

₹ 79,255.20

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1103455

Original Equipment Manufacturer

SICK SENSORS

Descripción
Medium Fluids
Measurement Switch, Continuous
Design Remote amplifier, length of cable 2 m
Probe type Rod probe
Probe length 700 mm
Process pressure –1 bar ... 10 bar
Process temperature –20 °C ... +100 °C
Communication interface IO-Link
Supply voltage 12 V DC ... 30 V DC 1)
Power consumption ≤ 100 mA at 24 V DC without output load
Initialization time ≤ 5 s
Protection class III
Connection type M12 round connector x 1, 8-pin
Length of cable 2 m
Output signal 1 x PNP + 3 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V
Output load 4 mA ... 20 mA < 350 Ohm at Uv > 12 V, 0 V ... 10 V > 750 Ohm at Uv 14 ≥ V
Hysteresis ≥ 2 mm 2)
Output current < 100 mA



SICK SENSORS 1103455 LFP0700-A5CMC Level Sensor
SICK SENSORS

1103455 | SICK SENSORS | LFP0700-A5CMC Level Sensor

₹ 79,255.20
Medium Fluids
Measurement Switch, Continuous
Design Remote amplifier, length of cable 2 m
Probe type Rod probe
Probe length 700 mm
Process pressure –1 bar ... 10 bar
Process temperature –20 °C ... +100 °C
Communication interface IO-Link
Supply voltage 12 V DC ... 30 V DC 1)
Power consumption ≤ 100 mA at 24 V DC without output load
Initialization time ≤ 5 s
Protection class III
Connection type M12 round connector x 1, 8-pin
Length of cable 2 m
Output signal 1 x PNP + 3 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V
Output load 4 mA ... 20 mA < 350 Ohm at Uv > 12 V, 0 V ... 10 V > 750 Ohm at Uv 14 ≥ V
Hysteresis ≥ 2 mm 2)
Output current < 100 mA
