SPARECRUX is NOT an authorized distributor for SICK SENSORS

1108734 | SICK SENSORS | IMM05-2B5PSVR8S Inductive Proximity Sensor

₹ 5,909.60

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1108734

Original Equipment Manufacturer

SICK SENSORS

Descripción

Housing Metric
Housing Standard design
Thread size M5 x 0.5
Diameter Ø 5 mm
Sensing range Sn 2.5 mm
Safe sensing range Sa 2.025 mm
Installation type Quasi-flush
Switching frequency 4,000 Hz
Connection type Cable with connector M8, 3-pin, 0.2 m
Switching output PNP
Switching output detail PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP67 1)
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 25 mm
Thread length 23 mm
Tightening torque, max. ≤ 1.5 Nm



SICK SENSORS 1108734 IMM05-2B5PSVR8S Inductive Proximity Sensor
SICK SENSORS

1108734 | SICK SENSORS | IMM05-2B5PSVR8S Inductive Proximity Sensor

₹ 5,909.60
Housing Metric
Housing Standard design
Thread size M5 x 0.5
Diameter Ø 5 mm
Sensing range Sn 2.5 mm
Safe sensing range Sa 2.025 mm
Installation type Quasi-flush
Switching frequency 4,000 Hz
Connection type Cable with connector M8, 3-pin, 0.2 m
Switching output PNP
Switching output detail PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP67 1)
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 25 mm
Thread length 23 mm
Tightening torque, max. ≤ 1.5 Nm
