1110956 | SICK SENSORS | MWS120-12A17C05000 Measuring Wheel Encoder

₹ 41,715.20

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1110956

Original Equipment Manufacturer

SICK SENSORS

Descripción
Communication interface Incremental
Communication Interface detail TTL / HTL
Connection type Male connector, M12, 8-pin, radial
Power consumption ≤ 0.5 W (without load)
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Service life of spring element > 1.5 million cycles
Mounting position relative to the measuring object Preferably from above, from below possible 4)



SICK SENSORS 1110956 MWS120-12A17C05000 Measuring Wheel Encoder
SICK SENSORS

1110956 | SICK SENSORS | MWS120-12A17C05000 Measuring Wheel Encoder

₹ 41,715.20
Communication interface Incremental
Communication Interface detail TTL / HTL
Connection type Male connector, M12, 8-pin, radial
Power consumption ≤ 0.5 W (without load)
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Service life of spring element > 1.5 million cycles
Mounting position relative to the measuring object Preferably from above, from below possible 4)
