SPARECRUX is NOT an authorized distributor for SICK SENSORS

1111178 | SICK SENSORS | MWS120-12M2QC14X12 Measuring Wheel Encoder

₹ 65,097.60

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1111178

Original Equipment Manufacturer

SICK SENSORS

Descripción
Connection type Male connector, M12, 4-pin, universal
Power consumption ≤ 1.5 W
Supply voltage 18 V ... 30 V
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Start up torque < 1 Ncm
Operating torque < 1 Ncm
Bearing lifetime 3.6 x 10^8 revolutions
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Service life of spring element > 1.5 million cycles



SICK SENSORS 1111178 MWS120-12M2QC14X12 Measuring Wheel Encoder
SICK SENSORS

1111178 | SICK SENSORS | MWS120-12M2QC14X12 Measuring Wheel Encoder

₹ 65,097.60
Connection type Male connector, M12, 4-pin, universal
Power consumption ≤ 1.5 W
Supply voltage 18 V ... 30 V
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Start up torque < 1 Ncm
Operating torque < 1 Ncm
Bearing lifetime 3.6 x 10^8 revolutions
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Service life of spring element > 1.5 million cycles
