SPARECRUX is NOT an authorized distributor for SICK SENSORS

1112907 | SICK SENSORS | MWS120-12N1NF18X00 Measuring Wheel Encoder

₹ 79,029.60

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1112907

Original Equipment Manufacturer

SICK SENSORS

Descripción
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Start up torque 0.5 Ncm
Operating torque 0.3 Ncm
Connection type Male connector, Female connector, 1x, 2x, M12, M12, 4-pin, 4-pin, axial, axial
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Communication interface PROFINET



SICK SENSORS 1112907 MWS120-12N1NF18X00 Measuring Wheel Encoder
SICK SENSORS

1112907 | SICK SENSORS | MWS120-12N1NF18X00 Measuring Wheel Encoder

₹ 79,029.60
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Start up torque 0.5 Ncm
Operating torque 0.3 Ncm
Connection type Male connector, Female connector, 1x, 2x, M12, M12, 4-pin, 4-pin, axial, axial
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Communication interface PROFINET
