1118572 | SICK SENSORS | MWS120-12M2QC00A30 Measuring Wheel Encoder

₹ 68,045.60

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1118572

Original Equipment Manufacturer

SICK SENSORS

Descripción

Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Communication interface IO-Link
Communication Interface detail IO-Link V1.1 / COM3 (230,4 kBaud)
Start up torque < 1 Ncm
Operating torque < 1 Ncm
Bearing lifetime 3.6 x 10^8 revolutions
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Service life of spring element > 1.5 million cycles



SICK SENSORS 1118572 MWS120-12M2QC00A30 Measuring Wheel Encoder
SICK SENSORS

1118572 | SICK SENSORS | MWS120-12M2QC00A30 Measuring Wheel Encoder

₹ 68,045.60
Measuring wheel circumference 200 mm 1)
Measuring wheel surface O-ring NBR70
Communication interface IO-Link
Communication Interface detail IO-Link V1.1 / COM3 (230,4 kBaud)
Start up torque < 1 Ncm
Operating torque < 1 Ncm
Bearing lifetime 3.6 x 10^8 revolutions
Minimum spring tension force 4 N 2) 3)
Max. permissible working area for the spring (continuous operation) ± 10 mm
Service life of spring element > 1.5 million cycles
