1121764 | SICK SENSORS | SLG25S-020SAR21D30 Automation Light Grid

₹ 51,558.40

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1121764

Original Equipment Manufacturer

SICK SENSORS

Descripción

Functional principle    Sender/receiver
Sensing range
Limit values    440 mm ... 4,900 mm
Parallel beam (recommended)    440 mm ... 3,500 mm
7 x cross beam (recommended)    470 mm ... 3,500 mm
Blind zone
Distance from 1st Beam to leading edge of housing (connection side)    4.6 mm
Distance from last beam to leading edge of housing (top)    19.6 mm 1)
Detection height    200 mm
Beam separation    25 mm
Optical light exit    Slim
Detection capability
Minimum detectable object (MDO), parallel beam    30 mm 2)
Minimum detectable object (MDO), 7 x cross beam    ≥ 12 mm 2)
Minimum object width (MOW), 7 x cross beam    31 % 3)
 4)
Factory setting
Beam function    7 x cross beam
Pin 2 (MF)    Teach-in input
Pin 4 (OUT)    Object detection output = “HIGH”
IO-Link (process data)    QL/Qint Status, System status, Beam status
Teach-in (default)    Auto teach-in
Adjustment
IO-Link    For configuring the sensor parameters and Smart Task functions
Emitted beam
Light source    LED
Type of light    Infrared light
Number of beams    8
