1135147 | SICK SENSORS | DBS60E-T5AQ01024 Incremental Encoder

₹ 22,521.60

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1135147

Original Equipment Manufacturer

SICK SENSORS

Descripción

Communication interface Incremental
Communication Interface detail TTL / RS-422
Number of signal channels 6-channel
Initialization time < 5 ms 1)
Output frequency + 300 kHz 2)
Mechanical design Through hollow shaft
Shaft diameter 12 mm
Shaft isolated
Flange type / stator coupling 2-sided stator coupling, slot, screw hole circle 63–83 mm
Weight + 0.25 kg 1)
Shaft material Stainless steel with plastic shaft
Flange material Aluminum
Housing material Aluminum
Material, cable PVC
Start up torque + 0.5 Ncm (+20 °C)
Operating torque 0.4 Ncm (+20 °C)
Permissible movement static

± 0.3 mm (radial)

± 0.5 mm (axial) 2)

Permissible movement dynamic

± 0.1 mm (radial)

± 0.2 mm (axial) 2)
