1221290 | SICK SENSORS | KTS-WB9124115AZZZZ Contrast Sensor

₹ 53,022.40

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1221290

Original Equipment Manufacturer

SICK SENSORS

Descripción
Special applications High Sensitivity
Device type Standard
Dimensions (W x H x D) 26 mm x 62 mm x 47.5 mm
Sensing distance ≤ 25 mm
Sensing distance tolerance ± 4 mm
Housing design Middle
Light source LED, RGB 1)
Wave length 470 nm, 525 nm, 625 nm
Light emission Long side of housing
Supply voltage 10.8 V DC ... 28.8 V DC 1)
Ripple ≤ 5 Vpp 2)
Current consumption < 100 mA 3)
Switching frequency

25 kHz 4)

 5)
Response time

20 µs 6)

 7)
Jitter 10 µs 8)
Switching output Push-pull: PNP/NPN
