SPARECRUX is NOT an authorized distributor for FESTO

14158 | FESTO | ISO Cylinder DNU-63-100-PPV-A

₹ 7,600.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

14158

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Stroke 100 mm
Piston Diameter 63 mm
Operating Pressure 0.6 to 10 bar (0.06 to 1 MPa)
Mode of Operation Double-acting
Mounting Position Optional
Cushioning Pneumatic cushioning, adjustable at both ends
Position Detection Via proximity switch
Symbol 00991223, 00991246, 00991267
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Lubrication Note Lubricated operation possible (lubricated operation will always be required)
Corrosion Resistance Class CRC 2 – Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Ambient Temperature -20 °C to +80 °C
Theoretical Force at 0.6 MPa Return stroke: 3,500 N Advance stroke: 3,500 N
Moving Mass for 0 mm Stroke 1,300 g
Additional Moving Mass/10 mm Stroke 80 g
Basic Weight for 0 mm Stroke 4,000 g
Additional Weight/10 mm Stroke 250 g
Type of Mounting Via female thread
Pneumatic Connection G1/2
RoHS Compliant Yes
Material Cover Coated die-cast aluminium
Material Piston Seal TPE-U (PU)
Material Piston Wrought aluminium alloy
Material Piston Rod High-alloy steel
Material Piston Rod Wiper TPE-U (PU)
Buffer Seal Material TPE-U (PU)
FESTO
