SPARECRUX is NOT an authorized distributor for FESTO

14323 | FESTO | ISO Cylinder DSNU-16- -P-A

₹ 5,375.22

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

Original Equipment Manufacturer

FESTO

Descripción
Parameter Value
Stroke 1 mm ... 200 mm
Piston diameter 16 mm
Piston rod thread M6
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Conforms to standard ISO 6432
Piston-rod end Male thread
Design Piston, Piston rod, Cylinder barrel
Position detection Via proximity switch
Variants Piston rod at one end
Operating pressure 0.1 MPa ... 1 MPa
Operating pressure 1 bar ... 10 bar
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required if used)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 6 according to ISO 14644-1
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.15 J
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 103.7 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 120.6 N
Moving mass for 0 mm stroke 23 g
Additional moving mass per 10 mm stroke 2 g
Basic weight for 0 mm stroke 89.9 g
Additional weight per 10 mm stroke 4.6 g
Type of mounting With accessories
Pneumatic connection M5
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy, colourless anodised
Material seals NBR, TPE-U (PU)
