159421 | FESTO | Connecting Cable

₹ 3,800.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

159421

Original Equipment Manufacturer

FESTO

Descripción

Specification Details
Product Name / Model SIM‑M8‑3GD‑5‑PU (Festo 159421)
Connector Type A M8 Receptacle (Straight socket)
Connector Type B Free end (open wires)
Number of Positions 3‑pole / 3‑wire
Cable Length 5 m (16.4 ft)
Material Cable sheath: TPE‑U (PU); Housing: TPE‑U (PU); Seals: NBR; Plug contacts: Gold‑plated brass; Locking nut: Nickel‑plated brass
Electrical Ratings Voltage: 0 – 60 VAC/DC; Current: 4 A at 40 °C (some sources state 3 A)
Protection Rating IP65 / IP68
Standards Compliance EN 61076‑2‑104, EN 61984; RoHS compliant; Free of SVHC (as of 23‑Jan‑2024)
Mechanical Durability Bending strength per Festo standard; energy‑chain tested for 5 million cycles, 75 mm bend radius
Ambient Temperature Range –25 °C to +80 °C (static); –5 °C to +80 °C for moving applications
Cable Cross‑Section 3 × 0.25 mm², diameter ~3.8 mm; color‑coded wires (blue, brown, black)
Country of Origin Bulgaria (last significant manufacturing step)
Weight (approx.) ~100–135 g (listed between 0.1 kg to 135 g depending on source)
