161131 | FESTO | Flanged Precision Pressure Gauge FMAP-63-16-1/4-EN

₹ 1,237.26

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

161131

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Indicating range 0 bar ... 16 bar0 psi ... 232 psi
Symbol 00991463
Conforms to standard EN 837-1
Nominal size of pressure gauge 63 mm
Explosion protection ATEX Zones 1, 2, 21, 22 – certificate must be observed
Design Bourdon tube pressure gauge
Type of mounting Front panel mounting
Operating medium Inert gases, neutral fluids
Note on operating and pilot medium No acetylene, no oxygen
Operating pressure 0 MPa ... 1.6 MPa0 bar ... 16 bar0 psi ... 232 psi
Alternating load factor 0.66
Measurement accuracy class 1
Degree of protection IP43
Media temperature -20 °C ... 60 °C
Ambient temperature -20 °C ... 60 °C
LABS (PWIS) conformity VDMA24364-B1/B2-L
Note on materials RoHS-compliant
Position of connection Centred, rear side
Pneumatic connection G1/4
Material in contact with the medium Brass
Material screwed plug Brass
Material housing ABS
Material screen SAN (Styrene-acrylonitrile)
Material mounting ring Steel
Housing colour Black
Product weight 120 g
Scale Double scale: Bar (outer) / psi (inner)
