163406 | FESTO | ISO Cylinder DNC-63-125-PPV-A

₹ 8,273.91

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

163406

Original Equipment Manufacturer

FESTO

Descripción
Parameter Specification
Stroke 125 mm
Piston Diameter 63 mm
Piston Rod Thread M16 x 1.5
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting Position Optional
Standard Conformance ISO 15552
Piston-Rod End Male thread
Design Piston, Piston rod, Profile barrel
Position Detection Via proximity switch
Symbol 00991235
Variants Piston rod at one end
Operating Pressure 0.06 MPa … 1.2 MPa (0.6 bar … 12 bar)
Mode of Operation Double-acting
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Lubrication Note Lubricated operation possible (if lubricated, always required)
Corrosion Resistance Class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Ambient Temperature Range -20 °C … 80 °C
Impact Energy in End Positions 0.5 J
Cushioning Length 22 mm
Theoretical Force at 0.6 MPa Return stroke: 1682 N, Advance stroke: 1870 N
Moving Mass (0 mm stroke) 663 g
Additional Moving Mass per 10 mm stroke 25 g
Basic Weight (0 mm stroke) 1709 g
Additional Weight per 10 mm stroke 73 g
Type of Mounting Via female thread
Pneumatic Connection G3/8
Note on Materials RoHS-compliant
Material Cover Die-cast aluminium (coated)
Material Seals TPE-U (PU)
Material Piston Rod High-alloy steel
Material Cylinder Barrel Wrought aluminium alloy (smooth anodised)
