SPARECRUX is NOT an authorized distributor for FESTO

164027 | FESTO | Flat Cylinder DZF-25-10-P-A

₹ 8,762.69

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

164027

Original Equipment Manufacturer

FESTO

Descripción
Property Value
Stroke 10 mm
Piston diameter 25 mm
Piston rod thread M5
Torsional backlash at piston rod ± 1 deg
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Protection against torque/guide Oval piston
Operating pressure 0.1 MPa ... 1 MPa / 1 bar ... 10 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Lubricated operation Possible (then always required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.1 J
Max. torque for protection against torsion 0.5 Nm
Theoretical force at 0.6 MPa (return stroke) 247 N
Theoretical force at 0.6 MPa (advance stroke) 295 N
Moving mass for 0 mm stroke 40 g
Additional moving mass per 10 mm stroke 6 g
Basic weight for 0 mm stroke 168 g
Additional weight per 10 mm stroke 18 g
Type of mounting Via female thread, With accessories
Pneumatic connection M5
Material cover Die-cast aluminium
Material seals HNBR, TPE-U(PU)
Material housing Anodised wrought aluminium alloy
Material piston seal NBR
Material piston rod High-alloy stainless steel
