SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

170692 | FESTO | On/off Valve HEL-D-MAXI

₹ 5,169.32

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

170692

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Function Exhaust-air function with flow control option
Type of Actuation Pneumatic
Sealing Principle Soft
Mounting Position Optional
Manual Override None
Design Piston gate valve
Type of Reset Mechanical spring
Type of Piloting Direct
Flow Direction Non-reversible
Symbol 00991513
Valve Function 2/2-way, closed, monostable
Operating Pressure 0.3 MPa ... 1.6 MPa (3 bar ... 16 bar)
Operating Medium Compressed air (ISO 8573-1:2010 [7:4:4]), Inert gases
Note on Operating and Pilot Medium Lubricated operation possible (if started, lubrication must continue)
Corrosion Resistance Class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Air Purity Class at Output Compressed air to ISO 8573-1:2010 [7:4:4], Inert gases
Media Temperature -10 °C ... 60 °C
Ambient Temperature -10 °C ... 60 °C
Product Weight 394 g
Type of Mounting In-line installation
Note on Materials RoHS-compliant
Material - Seals NBR
Material - Housing Die-cast aluminium
