SPARECRUX is NOT an authorized distributor for ALLEN BRADLEY

1734-IT2I | ALLEN BRADLEY | POINT I/O 2-Channel Thermocouple Input Module with Cold Junction Compensation

₹ 20,613.94

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1734-IT2I_Allen_Bradley

Original Equipment Manufacturer

ALLEN BRADLEY

Descripción

Specification

Description

Input Channels

2

Supported Thermocouple Types

J, K, T, E, R, S, B, N, C

Temperature Range

Dependent on thermocouple type; e.g., Type K: -270 to +1370 °C

Resolution

0.1 °C

Accuracy

±0.5 °C

Input Impedance

>10 MΩ

Cold Junction Compensation

Automatic

Conversion Rate

400 ms per channel

Power Consumption

0.75 W max

Power Dissipation

2.6 BTU/hr max

Operating Temperature Range

0…55 °C (32…131 °F)

Storage Temperature Range

-40…85 °C (-40…185 °F)

Dimensions (HxWxD)

56.6 x 12 x 75.5 mm (2.23 x 0.47 x 2.97 in.)

Certifications

CE, UL, c-UL, Class I Division 2, ATEX Zone 2, IECEx

ALLEN BRADLEY

1734-IT2I | ALLEN BRADLEY | POINT I/O 2-Channel Thermocouple Input Module with Cold Junction Compensation

₹ 20,613.94

Specification

Description

Input Channels

2

Supported Thermocouple Types

J, K, T, E, R, S, B, N, C

Temperature Range

Dependent on thermocouple type; e.g., Type K: -270 to +1370 °C

Resolution

0.1 °C

Accuracy

±0.5 °C

Input Impedance

>10 MΩ

Cold Junction Compensation

Automatic

Conversion Rate

400 ms per channel

Power Consumption

0.75 W max

Power Dissipation

2.6 BTU/hr max

Operating Temperature Range

0…55 °C (32…131 °F)

Storage Temperature Range

-40…85 °C (-40…185 °F)

Dimensions (HxWxD)

56.6 x 12 x 75.5 mm (2.23 x 0.47 x 2.97 in.)

Certifications

CE, UL, c-UL, Class I Division 2, ATEX Zone 2, IECEx
