1738-IB8M12 | ALLEN BRADLEY | ArmorPoint I/O 8-Channel 24V DC Input Module with M12 Connectors

₹ 17,110.42

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1738-IB8M12

Original Equipment Manufacturer

ALLEN BRADLEY

Descripción

Catalog Number 1738-IB8M12
Module Type ArmorPoint 8 Point Input Module
Number of Inputs 8 sinking inputs
Input Voltage Range 10–28.8V DC
Nominal Input Voltage 24V DC
Input Current (per channel) 2 mA at 24V DC
Input Delay Time 0.5 ms (hardware filter), plus 0–65 ms (programmable filter)
PointBus Current 75 mA
Power Dissipation 0.7 W at 28.8V DC
Thermal Dissipation 2.4 BTU/hr at 28.8V DC
Operating Temperature Range -20°C to 60°C (-4°F to 140°F)
Storage Temperature Range -40°C to 85°C (-40°F to 185°F)
Relative Humidity 5% to 95% non-condensing
Vibration 5 g @ 10–500 Hz
Shock 30 g operational, 50 g non-operational
Certifications CE, UL, cUL, ATEX
