1738-OB16E19M23 | ALLEN BRADLEY | ArmorPoint I/O 16-Channel 24V DC Output Module with Electronic Fusing and M23 Connectors
₹ 26,596.69
No se ha podido cargar la disponibilidad de recogida
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1738-OB16E19M23
Original Equipment Manufacturer
ALLEN BRADLEY
Descripción
Attribute
Value
Number of Outputs
16 sourcing outputs
On-State Voltage Drop
0.2V DC maximum
On-State Voltage Range
10V DC minimum to 28.8V DC maximum
On-State Current per Channel
1.0 mA minimum to 0.5 A maximum (electronically protected)
Off-State Voltage
28.8V DC maximum
External DC Supply Voltage
10V DC to 28.8V DC (24V DC nominal)
Off-State Current Leakage
0.5 mA
Output Current Rating
4.0 A per module maximum; 0.5 A per channel maximum
Output Surge Current
1 A maximum (electronically protected)
Output Delay Time (OFF to ON / ON to OFF)
0.1 ms
PointBus Current
150 mA at 5V DC maximum
Power Dissipation
3.0 W at 28.8V DC
Thermal Dissipation
10.3 BTU/hr at 28.8V DC
Isolation Voltage
50V (continuous), Reinforced Insulation Type, field-side to system; Type tested at 1000V DC for 60 s, field-side to system; No isolation between individual channels
Dimensions (HxWxD)
120 x 72 x 42 mm (4.72 x 2.83 x 4.25 in), including I/O and mounting base
#8 screw; 0.85 Nm (7.5 lb-in) in Aluminum; 1.81 Nm (16 lb-in) in Steel
