SPARECRUX is NOT an authorized distributor for ALLEN BRADLEY

This product has been discontinued, and manufacturer warranty or support may no longer be available.

Agotado

1738-OB8EM23 | ALLEN BRADLEY | ArmorPoint I/O 8-Channel 24V DC Output Module with Electronic Fusing and M23 Connectors

₹ 22,363.16

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1738-OB8EM23

Original Equipment Manufacturer

ALLEN BRADLEY

Descripción
Attribute Value
Number of Outputs 8 sourcing outputs
Output Voltage Range 10V DC to 28.8V DC (24V DC nominal)
Output Current Rating 1.0 A per channel; 2.0 A per module maximum
Off-State Leakage Current 0.5 mA maximum
Output Delay Time (OFF to ON / ON to OFF) 0.1 ms
PointBus Current 75 mA at 5V DC maximum
Power Dissipation 2.0 W at 28.8V DC
Thermal Dissipation 6.8 BTU/hr at 28.8V DC
Isolation Voltage 50V (continuous), Reinforced Insulation Type, field-side to system; Type tested at 1000V DC for 60 s, field-side to system; No isolation between individual channels
Dimensions (HxWxD) 120 x 36 x 42 mm (4.72 x 1.42 x 1.65 in), including I/O and mounting base
Weight 150 g (5.29 oz)
LED Indicators 8 yellow input/output status, logic side; 1 green/red network status, logic side; 1 green/red module status, logic side; 1 red fault status, logic side
Wiring Category 1 - on signal ports
Keyswitch Position 1
Enclosure Type Rating Meets IP65/66/67/69K (when marked)
Mounting Base Screw Torque #8 screw; 0.85 Nm (7.5 lb-in) in Aluminum; 1.81 Nm (16 lb-in) in Steel
