1738-SSIM23 | ALLEN BRADLEY | ArmorPoint I/O Synchronous Serial Interface (SSI) Absolute Encoder Module

₹ 26,247.88

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1738-SSIM23

Original Equipment Manufacturer

ALLEN BRADLEY

Descripción
Attribute Value
Number of Channels 1 SSI channel
Input Voltage Range 24V DC nominal
Data Format Binary or Gray code
Clock Frequency 62.5 kHz to 1 MHz
Data Length 8 to 32 bits
PointBus Current 75 mA at 5V DC maximum
Power Dissipation 1.5 W maximum
Thermal Dissipation 5.1 BTU/hr maximum
Isolation Voltage 50V (continuous), Reinforced Insulation Type, field-side to system; Type tested at 1000V DC for 60 s, field-side to system; No isolation between individual channels
Dimensions (HxWxD) 120 x 36 x 42 mm (4.72 x 1.42 x 1.65 in), including I/O and mounting base
Weight 150 g (5.29 oz)
LED Indicators 1 green/red module status, logic side; 1 green/red network status, logic side; 1 green/red channel status, logic side
Wiring Category 1 - on signal ports
Keyswitch Position 4
Enclosure Type Rating Meets IP65/66/67/69K (when marked)
Mounting Base Screw Torque #8 screw; 0.85 Nm (7.5 lb-in) in Aluminum; 1.81 Nm (16 lb-in) in Steel
