177692 | FESTO | Push-in L-connector CQL-15

₹ 306.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

177692

Original Equipment Manufacturer

FESTO

Descripción

Feature Specification
Nominal size 12 mm
Mounting position Optional
Size of pack 1
Design Push-pull principle
Operating pressure complete range -0.95 bar ... 7 bar
Temperature-dependent operating pressure -0.95 bar ... 15 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364 zone III
Suitable for use with food See supplementary material information
Ambient temperature -25 °C ... 70 °C
Product weight 20 g
Pneumatic connection, port 1 For pipe/tubing O.D. 15 mm
Pneumatic connection, port 2 For pipe/tubing O.D. 15 mm
Note on materials RoHS-compliant
Material housing POM
Material release ring POM
Material tubing clamp component High-alloy stainless steel
