SPARECRUX is NOT an authorized distributor for FESTO

186161 | FESTO | Push-in T-fitting QST-G1/4-8

₹ 325.46

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

186161

Original Equipment Manufacturer

FESTO

Descripción
Parameter Specification
Size Standard
Nominal size 6.7 mm
Type of seal on screwed plug Sealing ring
Mounting position Optional
Design T-shape
Design principle Push-pull principle
Size of pack 10
Operating pressure (complete temp. range) -0.095 MPa ... 0.6 MPa / -0.95 bar ... 6 bar / -13.775 psi ... 87 psi
Temperature-dependent operating pressure -0.095 MPa ... 1.4 MPa / -0.95 bar ... 14 bar / -13.775 psi ... 203 psi
Note on operating pressure Water: max. 0.6 MPa at max. 50°C
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free)
Note on operating and pilot medium Lubricated operation possible; Water G-thread only with sealing ring type OL accessory
Corrosion resistance class (CRC) 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Ambient temperature -10 °C ... 80 °C
Nominal torque 9 Nm
Tolerance for nominal tightening torque ± 20%
Product weight 27 g
Number of outputs 2
Number of supply lines 1
Type of mounting External hexagon, size 17 mm
Pneumatic connection, port 1 Male thread G1/4
Pneumatic connection, port 2 For tubing outside diameter of 8 mm
Colour of release ring Blue
Material screwed plug Nickel-plated brass
Material housing PBT (Polybutylene Terephthalate)
Material release ring POM (Polyoxymethylene)
Material tubing seal NBR (Nitrile Butadiene Rubber)
Material tubing clamp component High-alloy stainless steel
RoHS compliance Yes
