18624 | FESTO | Connecting Cable KMP3-25P-16-5

₹ 3,690.82

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

18624

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Based on standard DIN 41652
Cable designation With accessories
Frequency of connection 50
Product weight 672 g
Electrical connection 1, function Field device side
Electrical connection 1, design Angular
Electrical connection 1, connection type Socket
Electrical connection 1, cable outlet Angled
Electrical connection 1, connector system Sub-D
Electrical connection 1, number of cores 25
Electrical connection 1, used cores 18
Electrical connection 1, mounting type 2× screw M3
Electrical connection 1, connection pattern 00995642
Electrical connection 2, function Controller side
Electrical connection 2, connection type Cable
Electrical connection 2, connector system Open end
Electrical connection 2, number of cores 18
Electrical connection 2, used cores 18
Operational voltage range DC 0 V ... 30 V
Nominal operating voltage DC 24 V
Current rating at 40° C 3 A
Immunity to surge 1 kV
Cable length 5 m
Cable characteristic Standard
Test conditions cable On request
Bending radius, fixed cable ≥ 45 mm
Bending radius, moving cable ≥ 90 mm
Cable diameter 8.5 mm
Cable diameter tolerance ± 0.5 mm
Cable structure 18 × 0.34 mm²
Nominal cross section conductor 0.34 mm²
Wire ends Cut off bluntly
Degree of protection IP65 (in assembled state)
Ambient temperature -25 °C ... 70 °C
Ambient temp. with moving cable -5 °C ... 70 °C
Storage temperature -25 °C ... 75 °C
CE mark In accordance with EU RoHS Directive
UKCA marking To UK RoHS instructions
LABS (PWIS) conformity VDMA24364-B2-L
Note on materials RoHS-compliant
Pollution degree 3
Material cable sheath PVC
Cable sheath colour Grey
Material housing PA (Polyamide)
Material seals NBR
Material electrical contact Gold-plated copper alloy
