SPARECRUX is NOT an authorized distributor for FESTO

189470 | FESTO | Mini Guided Drive DFC-10-20-P-A-GF

₹ 18,451.51

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

189470

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Stroke 20 mm
Piston Diameter 10 mm
Drive Type Yoke
Guide Type Plain-bearing guide
Mounting Position Optional
Position Detection Via proximity switch
Symbol 00991737
Cushioning Elastic cushioning rings/plates (both ends)
Operating Pressure 0.1 – 1 MPa (1 – 10 bar)
Operating Medium Compressed air (ISO 8573-1:2010 [7:4:4])
Lubrication Note Lubricated operation possible (then always required)
Mode of Operation Double-acting
Ambient Temperature –5 °C to +60 °C
Max. Speed 1 m/s
Corrosion Resistance (CRC) 2 – Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B2-L
Impact Energy (at end positions) 0.05 J
Max. Load at 15 mm from Yoke Plate (xs) 12.2 N
Max. Moment Mx 0.4 Nm
Theoretical Force @ 6 bar (Advance) 47 N
Theoretical Force @ 6 bar (Return) 35 N
Distance to Load Centre (xs) 15 mm
Moving Mass 27.2 g
Weight (Total Product) 117 g
Pneumatic Connection M5
