192577 | FESTO | Lubricator LOE-D-MAXI

₹ 6,198.98

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

192577

Original Equipment Manufacturer

FESTO

Descripción

Parameter Details
Size Maxi
Series D
Mounting position Vertical +/-5°
Design Proportional standard mist lubricator
Max. oil capacity 190 cm³
Bowl guard Metal bowl guard
Symbol 00991532
Operating pressure 0 MPa ... 1.6 MPa
0 bar ... 16 bar
0 psi ... 232 psi
Min. flow rate for lubricator function 10 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4], Inert gases
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -10 °C ... 60 °C
Air purity class at output Compressed air to ISO 8573-1:2010 [7:4:-], Inert gases
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Product weight 1100 g
Type of mounting With accessories
Note on materials RoHS-compliant
Material bowl PC
