193147 | FESTO | One-way Flow Control Valve GRLA-1/4-QS-8-D

₹ 719.09

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

193147

Original Equipment Manufacturer

FESTO

Descripción

Parameter Value
Valve Function Exhaust air one-way flow control
Pneumatic Connection, Port 1 QS-8
Pneumatic Connection, Port 2 G1/4
Adjustment Component Slotted head screw
Type of Mounting Screw-in
Mounting Position Optional
Symbol 00991452
Standard Nominal Flow Rate (Flow Control Direction) 475 l/min
Standard Nominal Flow Rate (Blocked Direction) 325 l/min ... 500 l/min
Standard Flow Rate (Flow Control Direction, 6→0 bar) 720 l/min
Standard Flow Rate (Non-return Direction, 6→0 bar) 610 l/min ... 760 l/min
Operating Pressure (Complete Temp. Range) 0.2 bar ... 10 bar
Ambient Temperature -10 °C ... 60 °C
Media Temperature -10 °C ... 60 °C
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on Operating Medium Lubricated operation possible (then required permanently)
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Cleanroom Class Class 4 according to ISO 14644-1
Maritime Classification See certificate
Nominal Torque 5 Nm
Tolerance for Nominal Tightening Torque ± 10%
Product Weight 42 g
Material (Screwed Plug) Wrought aluminium alloy
Material (Seals) NBR
Material (Release Ring) POM
Material (Adjusting Screw) Brass
Material (Swivel Fitting) Die-cast zinc, chromated
Note on Materials RoHS-compliant
FESTO
