193149 | FESTO | One-way Flow Control Valve GRLA-3/8-QS-6-D

₹ 965.93

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

193149

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Valve Function Exhaust air one-way flow control function
Pneumatic Connection, Port 1 QS-6
Pneumatic Connection, Port 2 G3/8
Adjustment Component Slotted head screw
Type of Mounting Screw-in
Standard Nominal Flow Rate (Flow Control Direction) 495 l/min
Standard Nominal Flow Rate (Blocked Direction) 320 l/min ... 495 l/min
Ambient Temperature -10 °C ... 60 °C
Maritime Classification See certificate
Mounting Position Optional
Symbol 00991452
Operating Pressure (Complete Temperature Range) 0.2 bar ... 10 bar
Standard Flow Rate (Flow Control Direction, 0.6→0 MPa) 740 l/min
Standard Flow Rate (Non-return Direction, 0.6→0 MPa) 840 l/min ... 890 l/min
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on Operating and Pilot Medium Lubricated operation possible (lubrication always required if applied)
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Cleanroom Class Class 4 according to ISO 14644-1
Media Temperature -10 °C ... 60 °C
Nominal Torque 10 Nm
Tolerance for Nominal Tightening Torque ± 10%
Product Weight 60 g
Material - Screwed Plug Wrought aluminium alloy
Material - Seals NBR
Material - Release Ring POM
Material - Adjusting Screw Brass
Material - Swivel Fitting Die-cast zinc, chromated
Note on Materials RoHS-compliant
