SPARECRUX is NOT an authorized distributor for FESTO

193973 | FESTO | Throttle Valve GRO-QS-6

₹ 904.01

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

193973

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Valve function Flow control function
Pneumatic connection, port 1 QS-6
Pneumatic connection, port 2 QS-6
Adjustment component Knurled screw
Type of mounting With through-hole, with accessories
Mounting position Optional
Standard nominal flow rate (flow control direction) 245 l/min
Standard nominal flow rate (blocked direction) 430 l/min
Operating pressure 0 bar ... 10 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (then always required)
Ambient temperature -10 °C ... 60 °C
Media temperature -10 °C ... 60 °C
Explosion protection Zone 1, Zone 2, Zone 21, Zone 22 (ATEX compliant)
Symbol 00991454
LABS (PWIS) conformity VDMA24364-B1/B2-L
Product weight 22 g
Note on materials RoHS-compliant
Material housing PA-reinforced
Material seals NBR
Material release ring POM
Material knurled head Reinforced PA
Material adjusting screw High-alloy steel
FESTO

193973 | FESTO | Throttle Valve GRO-QS-6

₹ 904.01
Parameter Specification
Valve function Flow control function
Pneumatic connection, port 1 QS-6
Pneumatic connection, port 2 QS-6
Adjustment component Knurled screw
Type of mounting With through-hole, with accessories
Mounting position Optional
Standard nominal flow rate (flow control direction) 245 l/min
Standard nominal flow rate (blocked direction) 430 l/min
Operating pressure 0 bar ... 10 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (then always required)
Ambient temperature -10 °C ... 60 °C
Media temperature -10 °C ... 60 °C
Explosion protection Zone 1, Zone 2, Zone 21, Zone 22 (ATEX compliant)
Symbol 00991454
LABS (PWIS) conformity VDMA24364-B1/B2-L
Product weight 22 g
Note on materials RoHS-compliant
Material housing PA-reinforced
Material seals NBR
Material release ring POM
Material knurled head Reinforced PA
Material adjusting screw High-alloy steel
