193990 | FESTO | ISO Cylinder DSNU-20-15-PPV-A-MQ

₹ 8,151.49

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

193990

Original Equipment Manufacturer

FESTO

Descripción
Parameter Specification
Stroke 1 mm ... 320 mm
Piston diameter 20 mm
Cushioning Elastic cushioning rings/plates at both endsSelf-adjusting pneumatic end-position cushioningPneumatic cushioning, adjustable at both ends
Mounting position Optional
Conforms to standard ISO 6432
Design Piston, Piston rod, Cylinder barrel
Position detection Via proximity switch
Variants Extended male piston rod threadPiston rod with female threadPiston rod with male thread shortened at one endExtended piston rodClamping unit on the piston rod
Axial supply port With direct mounting
Lateral supply port With protection against rotation
High corrosion protection Yes
Uniform, slow movement Yes
Low friction Yes
Through piston rod Yes
Heat-resistant seals max. temperature 120°C
Piston rod at one end Yes
Protection against torque/guide Square piston rod
Operating pressure 0.1 MPa ... 1 MPa (1 bar ... 10 bar)
Mode of operation Double-acting
CE mark Yes (see declaration of conformity)
Explosion Protection Directives To EU Explosion Protection Directive (ATEX)UKCA marking (see declaration of conformity)To UK EX instructions
Explosion protection certification EPL Db (GB)EPL Gb (GB)
Explosion protection zones Zone 1 (ATEX, UKEX)Zone 2 (ATEX)Zone 21 (ATEX, UKEX)Zone 22 (ATEX)
ATEX category Gas: II 2GDust: II 2D
Explosion ignition protection type Gas: Ex h IIC T4 GbDust: Ex h IIIC T120°C Db
Explosion ambient temperature -20°C ≤ Ta ≤ +60°C
