SPARECRUX is NOT an authorized distributor for SICK SENSORS

2022814 | SICK SENSORS | WE34-V540 Through-beam photoelectric sensor

₹ 15,692.56

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

2022814

Original Equipment Manufacturer

SICK SENSORS

Descripción

The WE34-V540 is the receiver unit of a through-beam photoelectric sensor pair from SICK's W34 series, designed to provide reliable object detection in industrial environments when paired with the appropriate sender unit.

  • Functional Principle: Through-beam photoelectric sensor (Receiver)
  • Sensing Range: Up to 50 meters with corresponding sender
  • Light Source: Visible red LED (660 nm)
  • Supply Voltage: 10 V DC to 30 V DC
  • Output Type: PNP, light/dark switching
  • Switching Frequency: 1,000 Hz
  • Response Time: ≤ 1 ms
  • Connection Type: M12, 5-pin male connector
  • Housing Material: ABS plastic
  • Enclosure Rating: IP67
  • Ambient Operating Temperature: –25 °C to +55 °C
  • Dimensions (L x W x H): 92 mm x 27 mm x 70 mm

The WE34-V540 receiver is ideal for long-range object detection applications, including conveyor systems and automated sorting systems, when paired with the appropriate sender unit.

2022814 | Sick We34-V540
SICK SENSORS

2022814 | SICK SENSORS | WE34-V540 Through-beam photoelectric sensor

₹ 15,692.56

The WE34-V540 is the receiver unit of a through-beam photoelectric sensor pair from SICK's W34 series, designed to provide reliable object detection in industrial environments when paired with the appropriate sender unit.

  • Functional Principle: Through-beam photoelectric sensor (Receiver)
  • Sensing Range: Up to 50 meters with corresponding sender
  • Light Source: Visible red LED (660 nm)
  • Supply Voltage: 10 V DC to 30 V DC
  • Output Type: PNP, light/dark switching
  • Switching Frequency: 1,000 Hz
  • Response Time: ≤ 1 ms
  • Connection Type: M12, 5-pin male connector
  • Housing Material: ABS plastic
  • Enclosure Rating: IP67
  • Ambient Operating Temperature: –25 °C to +55 °C
  • Dimensions (L x W x H): 92 mm x 27 mm x 70 mm

The WE34-V540 receiver is ideal for long-range object detection applications, including conveyor systems and automated sorting systems, when paired with the appropriate sender unit.
