536417 | FESTO | Compact Cylinder AEN-25-5-A-P-A

₹ 7,015.85

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

536417

Original Equipment Manufacturer

FESTO

Descripción
Parameter Specification
Stroke 1 mm ... 25 mm
Piston diameter 25 mm
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Conforms to standard ISO 21287
Design Piston
Piston rod Profile barrel
Position detection Via proximity switch
Variants
  • Improved running performance
  • Extended male piston rod thread
  • Custom thread on the piston rod
  • Extended piston rod
  • With protection against rotation
  • Heat-resistant seals max. 120°C
  • Laser etched rating plate
  • Pulling
Piston rod at one end Yes
Operating pressure 0.1 MPa ... 1 MPa / 1 bar ... 10 bar
Mode of operation Pushing, Single-acting, Pulling
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 120 °C
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 196 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 246 N
Additional weight per piston rod extension of 10 mm 6 g
Additional weight per piston rod thread extension of 10 mm 4 g
Type of mounting Either:
With through-hole
Via female thread
With accessories
Pneumatic connection M5
Note on materials RoHS-compliant
Material collar screws Steel
Material cover Anodised wrought aluminium alloy
Material piston rod High-alloy steel
Material cylinder barrel Smooth-anodised wrought aluminium alloy
