548713 | FESTO | Soft Start/quick Exhaust Valve MS6(N)-SV

₹ 38,000.00

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

548713

Original Equipment Manufacturer

FESTO

Descripción
Parameter Specification
Series MS
Size 6
Grid dimension 62 mm
Safety function Exhaust
Prevention of unexpected start-up (pressurisation) Yes
Switching frequency min. 1/month
Design Piston gate valve
Piston seat Yes
Type of actuation Electric
Pilot air supply Internal
Sealing principle Soft
Exhaust-air function Without flow control option
Manual override None
On pilot solenoid valves Non-detenting; on soft-start/quick exhaust valve: detenting, self-resetting
Type of reset Mechanical spring
Type of piloting Pilot actuated
Valve function 3/2-way, closed, monostable
Soft-start function Yes
Operating pressure 0.3 MPa ... 1 MPa
LABS (PWIS) conformity VDMA24364-B1/B2-L
Degree of protection IP65
With plug socket Yes
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Storage temperature -10 °C ... 60 °C
Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Approval RCM trademark, c UL us - Recognized (OL), KC mark, KC-EMV, CE mark, To EU EMC Directive, To EC Machinery Directive, To EU Low Voltage Directive, In accordance with EU RoHS Directive, UKCA marking, To UK instructions for EMC, To UK regulations for machines, To UK RoHS instructions
