552940 | FESTO | Fine Filter MS9-LFM

₹ 45,818.50

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

552940

Original Equipment Manufacturer

FESTO

Descripción

Parameter Details
Series MS
Size 9
Design Fibre filter
Grade of filtration 0.01 µm ... 1 µm
Condensate drain Fully automatic
Fully automatic, electrically actuated
Manual, non-detenting
Manually rotating
Semi-automatic
Operating pressure 0 MPa ... 2 MPa
0 bar ... 20 bar
0 psi ... 290 psi
Operating medium Compressed air to ISO 8573-1:2010 [6:-:4]
Max. condensate volume 225 ml
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Differential pressure display Visual display
Approval c UL us - Recognized (OL)
CE mark (see declaration of conformity)
To EU Explosion Protection Directive (ATEX)
UKCA marking (see declaration of conformity)
To UK EX instructions
Explosion protection certification outside the EU
EPL Db (GB)
EPL Gb (GB)
FESTO
