SPARECRUX is NOT an authorized distributor for SICK SENSORS

6013695 | SICK SENSORS | VS/VE18-4P3240 Through-beam Photoelectric Sensor

₹ 9,708.00

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6013695

Original Equipment Manufacturer

SICK SENSORS

Descripción

Functional principle Through-beam photoelectric sensor
Dimensions (W x H x D) 18 mm x 18 mm x 78 mm
Housing design (light emission) Cylindrical
Housing length 78 mm
Thread diameter (housing) M18 x 1
Optical axis Axial
Sensing range max. 0 m ... 20 m
Sensing range 0 m ... 14 m
Focus Approx. 2.8°
Type of light Infrared light
Light source LED 1)
Light spot size (distance) Ø 700 mm (14 m)
Housing material Metal, Nickel-plated brass
Enclosure rating IP67
Test input sender off TE to 0 V
Ambient operating temperature –25 °C ... +70 °C



SICK SENSORS 6013695 VS/VE18-4P3240 Through-beam Photoelectric Sensor
SICK SENSORS

6013695 | SICK SENSORS | VS/VE18-4P3240 Through-beam Photoelectric Sensor

₹ 9,708.00
Functional principle Through-beam photoelectric sensor
Dimensions (W x H x D) 18 mm x 18 mm x 78 mm
Housing design (light emission) Cylindrical
Housing length 78 mm
Thread diameter (housing) M18 x 1
Optical axis Axial
Sensing range max. 0 m ... 20 m
Sensing range 0 m ... 14 m
Focus Approx. 2.8°
Type of light Infrared light
Light source LED 1)
Light spot size (distance) Ø 700 mm (14 m)
Housing material Metal, Nickel-plated brass
Enclosure rating IP67
Test input sender off TE to 0 V
Ambient operating temperature –25 °C ... +70 °C
