6030125 | SICK SENSORS | MRA-F080-103D2 Wire Draw Mechanism

₹ 95,814.40

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6030125

Original Equipment Manufacturer

SICK SENSORS

Descripción

Items supplied Without encoder
Measurement range 0 m 3 m
Reproducibility ≤ 1 mm
Linearity ≤ ± 2 mm
Hysteresis ≤ 2 mm
Weight 1.5 kg Wire draw mechanism
Weight (measuring wire) 7.1 g/m
Measuring wire material Highly flexible stranded steel 1,4401 stainless steel V4A
Material, spring housing Die-cast zinc
Housing material, wire draw mechanism Aluminum (anodized), aluminum die cast (nickel-plated)
Length of wire pulled out per revolution 200 mm
Actual wire draw length 3.2 m
Spring return force 6 N 14 N 1)
Measuring wire diameter 1.35 mm
Wire acceleration 40 m/s²
Operating speed 8 m/s
