6069560 | SICK SENSORS | LFV200-XXHCNTPVL Level Sensor

₹ 44,395.20

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6069560

Original Equipment Manufacturer

SICK SENSORS

Descripción

Medium Fluids
Measurement Switch
Probe length 117 mm
Process pressure –1 bar ... 64 bar
Process temperature –40 °C ... +150 °C
Fill material density 0.7 g/cm³ ... 2.5 g/cm³
Supply voltage 9.6 V DC ... 35 V DC
Residual ripple ≤ 5 Vpp
Power consumption ≤ 10 mA
Initialization time < 2 s
VDE protection class 2
Connection type Valve plug DIN 43650
Output signal Transistor output PNP
Hysteresis 2 mm
Output current < 250 mA
Inductive load ≤ 1 H
Capacitive load 100 nF
