750-466 | WAGO | 2-Channel Analog Input, 4–20 mA, Single-Ended

₹ 53,978.25

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-466

Original Equipment Manufacturer

WAGO

Descripción
Parameter Value
Number of analog inputs 2
Total number of channels (module) 2
Signal type Current
Signal type (current) 4 … 20 mADC
Sensor connection 2 x (2-wire, 3-wire)
Input voltage (max.) 10 V
Signal characteristics Single-ended
Resolution [bit] 12Bit
Input resistance (max.) 220Ω
Connection technology: I/O 8 x CAGE CLAMP®
Connectable conductor materials Copper
Connection type Inputs/Outputs
Solid conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Strip length 8 … 9 mm / 0.31 … 0.35 inches
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Mounting type DIN-35 rail
Pluggable connector Fixed
Color Light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 0.822 MJ
Weight 49.9 g
Conformity marking CE
