A9R11491 | SCHNEIDER ELECTRIC | Acti 9 iID - RCCB - 4P - 100A - 30mA - Type AC

₹ 8,874.90

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

A9R11491

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Descripción
Device Type Residual Current Circuit Breaker (RCCB)
Poles 4‑Pole (4P), neutral on left
Rated Current (In) 100 A
Network Type AC
Sensitivity 30 mA, Type AC, instantaneous
Rated Operational Voltage (Ue) 380…415 V AC, 50/60 Hz
Breaking / Making Capacity 1500 A (Im / Idm), Conditional short‑circuit: 10 kA
Insulation Voltage (Ui) 500 V AC
Impulse Withstand (Uimp) 6 kV
Contact Indicator Front mechanical Visitrip indicator
Control Type Toggle switch with green Vis iSafe strip
Mounting Clip-on onto DIN-rail
Unit Pitch 8 × 9 mm modular pitches
Dimensions (H × W × D) 91 × 72 × 73.5 mm
Weight ~0.37 kg
Color White (RAL 9003)
Mechanical Endurance 20,000 cycles
Electrical Endurance 10,000 cycles (AC‑1)
Terminal Connections Single terminal top/bottom, solid up to 35 mm², torque 3.5 Nm
Operating Temp. −5 °C to +60 °C; Storage −40 °C to +85 °C
IP Rating IP20 (device) / IP40 within modular enclosure
Standards & Certifications EN/IEC 61008‑1; ISI, SNI; RoHS/REACh; Green Premium
Warranty 18 months
