BIL-50320 | BCH ELECTRIC | Single Door Box Enclosure

₹ 10,984.85

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

BIL-50320

Original Equipment Manufacturer

BCH ELECTRIC

Descripción

Specification Details
BCH Cat Code BIL-50320
Enclosure Size (W x H x D) 600 mm x 800 mm x 300 mm
Mounting Plate Size (W x H) 540 mm x 776 mm
Thickness of Enclosure Body: 1.6 mm CRCA, Front door: 1.6 mm CRCA, Gland plate: 2.0 mm CRCA, Mounting plate: 2.0 mm GPSP
Surface Finish Enclosure body, door, gland plate: Powder coated with Tri-catatonic Zn Phosphating; Mounting Plate: GPSP finish
Colour Structure RAL-7035
Supply Includes Enclosure with Hinged door (PU Foam gasket), Gland Plate, Mounting Plate, Triangular insert Cam lock
Protection Category IP 55 as per IEC 60529:2013
Mechanical Impact IK 10 as per IEC 62262:2002
Number of Doors 1
Number of Locks 2
Number of Gland Plates 2
Door Opening 120°
Weight of Enclosure 31 Kg
