SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

CAD32MD | SCHNEIDER ELECTRIC | TeSys D Control Relay - 3 NO + 2 NC - <= 690 V - 220 V DC Standard Coil

₹ 2,458.60

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CAD32MD

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Descripción

Product Name TeSys CAD
Product or Component Type Control relay
Device Short Name CAD
Contactor Application Control circuit
Control Circuit Voltage 220 V DC
Mechanical Durability 30 Mcycles
Maximum Operating Rate 180 cyc/mn
Time Constant 28 ms
Inrush Power 5.4 W (at 20 °C)
Hold-in Power Consumption 5.4 W (at 20 °C)
Minimum Switching Voltage 17 V
Minimum Switching Current 5 mA
Height 77 mm
Width 45 mm
Depth 93 mm
Net Weight 0.58 kg
SCHNEIDER ELECTRIC

CAD32MD | SCHNEIDER ELECTRIC | TeSys D Control Relay - 3 NO + 2 NC - <= 690 V - 220 V DC Standard Coil

₹ 2,458.60
Product Name TeSys CAD
Product or Component Type Control relay
Device Short Name CAD
Contactor Application Control circuit
Control Circuit Voltage 220 V DC
Mechanical Durability 30 Mcycles
Maximum Operating Rate 180 cyc/mn
Time Constant 28 ms
Inrush Power 5.4 W (at 20 °C)
Hold-in Power Consumption 5.4 W (at 20 °C)
Minimum Switching Voltage 17 V
Minimum Switching Current 5 mA
Height 77 mm
Width 45 mm
Depth 93 mm
Net Weight 0.58 kg
